Connect Tech社製品

型番：NVIDIA® Jetson carrire board
Interface1：1x USB 3.1¸ 2x GbE¸
Interface2：2x 2-lane MIPI CSI-2¸ 1x USB OTG
Interface3：1x SD card slot¸ 3x 3.3V UART¸ 2 x I2C¸ 1x CAN 2.0b¸ and 1x SPI
電源電圧：+5V DC Input
温度範囲： -40℃ to +85℃
ボードサイズ：82.6mm x 58.8mm
適合GPU：jettson　NANOxavier NX

仕様書ダウンロード

型番：Embedded Systems
Interface1：GMSL¸ USB 3.0¸ USB 2.0¸ CAN 2.0b¸ USB OTG¸ RS-485¸ I2C¸ GPIO¸ SPI¸ PWM
Interface3：1x NVMe (PCIe x4¸ 2280)¸ 1x SD card slot
温度範囲： -20℃ to +80℃
ボードサイズ：135mm x 50mm x 105mm
適合GPU：Jettson Xavier NX

仕様書ダウンロード

型番：NVIDIA® Jetson carrire board
Interface1：PoE PD (NGX002) capable¸ power via separate input or over Ethernet (IEEE 802.3af-2003 and IEEE 802.3at2009 compatible)
Interface3：1 x GbE¸ 1x NVMe (M.2 M-Key). 1 microSD¸ 4x GPIO¸ I2C¸ USB Console/UART¸ US OTG for programming
電源電圧：DC barrel power input also available
ボードサイズ： 145mm x 64.5mm
適合GPU：jettson　NANOxavier NX

仕様書ダウンロード

型番：NVIDIA® Jetson Carrire board
Interface1：1x USB 3.1¸ 2x GbE¸
Interface2：2x 2-lane MIPI CSI-2¸ 1x USB OTG
Interface3：1x SD card slot¸ 3x 3.3V UART¸ 2 x I2C¸ 1x CAN 2.0b¸ and 1x SPI
電源電圧：+5V DC Input
温度範囲： -40℃ to +85℃
ボードサイズ：82.6mm x 58.8mm
適合GPU：jettson　NANOxavier NX

仕様書ダウンロード

型番：NVIDIA® Jetson Carrire board
Interface1：PoE PD (NGX002) capable¸ power via separate input or over Ethernet (IEEE 802.3af-2003 and IEEE 802.3at2009 compatible)
Interface3：1 x GbE¸ 1x NVMe (M.2 M-Key). 1 microSD¸ 4x GPIO¸ I2C¸ USB Console/UART¸ US OTG for programming
電源電圧：DC barrel power input also available
ボードサイズ： 145mm x 64.5mm
適合GPU：jettson　NANOxavier NX

仕様書ダウンロード

型番：Heat Sinks
ボードサイズ：61mm x 40mm x 4.2mm
適合GPU：Designed to fit the NVIDIA® Jetson Nano™ production modules
その他仕様：NVIDIA® Jetson Nano™ production module does not include a thermal transfer plate
冷却方式：CTI provides Thermal transfer plate that users can integrate into a custom chassis or to other interface material for further cooling

型番：Heat Sinks
ボードサイズ：61mm x 40mm x 16mm
適合GPU：Designed to fit the NVIDIA® Jetson Nano™ modules
冷却方式：Dissipates the heat produced by the module through convection

型番：Heat Sinks
ボードサイズ：61mm x 40mm x 16mm
適合GPU：Designed to fit the NVIDIA® Jetson Nano™ modules
冷却方式：Dissipates the heat produced by the module through convection

型番：Enclosures
適合GPU：In support of the NVIDIA® Jetson Nano™ community¸ one filled with makers¸ learners¸ developers and students¸ Connect Tech is offering free public download of a 3D pri
その他仕様：Nano-Pac¸ which can be 3D printed as a Jetson Nano Development Kit enclosure.

型番：Embedded Systems
Interface1：1x USB 3.1 Gen 2 Type C (With OTG) 2x USB 3.1 Gen 2 at Rear I/O (1x OTG capable)
Interface3：2x HDMI
電源電圧： +10V to +65V DC Input (+28V Nominal)
温度範囲： -25℃ to +70℃

仕様書ダウンロード

型番：NVIDIA® Jetson™ Carrire board
Interface1：3x USB 3.1 Ports (Type-C)
Interface2：1x USB OTG (Micro-AB)
Interface3：2 PCIe Gen2 x4 Connections (for ximea xiX cameras)6 x2 Lane MIPI CSI-2 or4 x4 Lane MIPI CSI-2
ボードサイズ：105mm x 105mm

仕様書ダウンロード

型番：NVIDIA® Jetson™ Carrire board
Interface1：1x USB OTG (Micro-AB)¸ 3x USB 3.1 Ports (Type-C)
Interface2：6x 2-lane or 4x 4-lane MIPI CSI Camera
Interface3：2x NVMe M.2 Key M Slots¸ 3x USB 3.1¸ 2x GbE
ボードサイズ：92mm x 105mm

仕様書ダウンロード

型番：NVIDIA® Jetson™ Carrire board
Interface1：8x Total (GMSL2/GMSL1)
Interface3：A single 4-lane MIPI CSI-2 v1.3 output from each Deserializer (16-lanes total)
温度範囲： -40℃ to +85℃

仕様書ダウンロード

型番：Adapter Board
Interface1：3x USB 2.03x USB 3.03x PCIe x1
温度範囲： -40℃ to +85℃
ボードサイズ：92mm x 105mm

仕様書ダウンロード

型番：Heat Sinks
ボードサイズ：100mm x 87mm x 36.7mm
適合GPU：Designed to fit the NVIDIA® Jetson AGX Xavier™ modules
冷却方式：Dissipates the heat produced by the module through a fan

型番：Heat Sinks
ボードサイズ：100mm x 87mm x 16mm
適合GPU：Designed to fit the NVIDIA® Jetson AGX Xavier™ modules
冷却方式：Dissipates the heat produced by the module through convection

型番：NVIDIA Jetson Carrier Boards
Interface1：1x USB 2.0 to miniPCIe Slot1x USB CLIENT2x USB 2.0¸ 2x USB 3.0
Interface2：6 x2 Lane MIPI CSI-2 OR 3 x4 Lane MIPI CSI-2
Interface3：1 x miniPCIe Slot with PCIe¸ USB + SIM
電源電圧：Wide Input +12V to +22V DC
温度範囲： -40℃ to +85℃ P5
ボードサイズ：125mm x 95mm

仕様書ダウンロード

型番：NVIDIA Jetson Carrier Boards
Interface1：1x USB 2.0¸ 1x USB 2.0 to miniPCIe Slot1x USB 3.0¸ 1x USB OTG
Interface3：1 x miniPCIe Slot with PCIe & USB
電源電圧： +12 DC Input Only
温度範囲： -40℃ to +85℃
ボードサイズ：178mm x 147.5mm

仕様書ダウンロード

型番：NVIDIA Jetson Carrier Boards
Interface1：1x USB OTG
Interface2：1 x MIPI CSI-2 Input¸ x4 or x2 lane configuration (30-pin connector)
電源電圧： +12V to +16V DC Input Range
温度範囲： -40℃ to +85℃
ボードサイズ：87mm x 50mm

仕様書ダウンロード

型番：NVIDIA Jetson Carrier Boards
Interface1：1x USB 3.0¸ 2x USB 2.0
Interface2：1x half size card or 1x full length card¸ PCIe and USB signaling (Mini PCIe)
Interface3：1x mSATA¸ half size card
温度範囲： -40℃ to +85℃
ボードサイズ：87mm x 57mm

仕様書ダウンロード

型番：NVIDIA Jetson Carrier Boards
Interface1：1x USB 2.0¸ 1x USB 3.0
Interface2： 2x 2-Lane (x2) MIPI CSI 2.0
Interface3：1x microSD
電源電圧： +9V to +14V DC
温度範囲： -40℃ to +85℃
ボードサイズ：87mm x 50mm

仕様書ダウンロード

型番：NVIDIA Jetson Carrier Boards
Interface1：1x USB 3.0
Interface3：1x microSD
電源電圧： +9V to +14V DC Nominal (+19V Peak)
温度範囲： -40℃ to +85℃
ボードサイズ：87mm x 50mm

仕様書ダウンロード

型番：NVIDIA Jetson Carrier Boards
Interface1：1x USB 3.0
Interface3：1x microSD
電源電圧： +9V to +14V DC Nominal (+19V Peak)
温度範囲： -40℃ to +85℃
ボードサイズ：87mm x 50mm

仕様書ダウンロード

型番：Embedded Systems
Interface1：1 x USB 3.0 Port (Type-A); 1 x USB OTG (Micro-AB); 1 x USB 2.0 (Type-A); 1 x USB 2.0 to miniPCIe Slot
Interface3：1x microSD Card Slot¸ 1x mSATA Full Sized Slot
電源電圧： +12 DC Input Only¸ No external 48V is required¸ carrier creates its own PoE power
温度範囲： -20℃ to +80℃
ボードサイズ：215mm x 154mm x 72.2mm

仕様書ダウンロード

型番：Embedded Systems
Interface1：1x USB OTG¸ 2x USB 2.0¸ 2x USB 3.0
Interface3：1 x miniPCIe Slot with PCIe & USB Connectivity
電源電圧： +12V DC Input Only (DC Barrel)
温度範囲： -20℃to +80℃
ボードサイズ：135mm x 50mm x 105mm

仕様書ダウンロード

型番：Embedded Systems
Interface1：1x USB OTG¸ 2x USB 2.0¸ 2x USB 3.0
Interface3：1 x miniPCIe Slot with PCIe & USB Connectivity
電源電圧： +12V DC Input Only (DC Barrel)
温度範囲： -20℃to +80℃
ボードサイズ：135mm x 50mm x 105mm

仕様書ダウンロード

型番：Embedded Systems
Interface1：2x 10G SFP+¸ 2x 1G SFP Uplink Capability
Interface3：3x 2.5″ SATA drives
電源電圧：100~240 VAC (Dual Redundant) with 650W output each
温度範囲： 0℃ to +60℃
ボードサイズ： Standard 1U Rackmount Height (1.75 inch / 44.45mm)、25 inch / 635mm Depth

仕様書ダウンロード

型番：Enclosures
Interface1：Specifically designed for use with Jetson™ TX2/TX1 and Orbitty Carrier
Interface2：2-Piece Metal Enclosure
form factor：Optional 2x SMA Antenna Connectors
ボードサイズ：95.2mm x 63mm x 58.2mm
適合GPU：Specifically designed for use with Jetson™ TX2/TX1 and Orbitty Carrier
その他仕様：2-Piece Metal Enclosure
冷却方式：(Orbitty¸ Module¸ Heat Sink – 204g [0.45lb])

仕様書ダウンロード

型番：VPX
電源電圧： +12V Input¸ 3V3_AUX (VS2 is not used)¸ 5V (VS3)
温度範囲： -40℃ to +85℃
その他仕様：1 TFLOP¸ 256 CUDA cores with NVIDIA® Pascal™ or Maxwell™ GPU Architecture
冷却方式：Conduction cooled

仕様書ダウンロード

型番：Heat Sinks
ボードサイズ：87mm x 50mm x 16mm
適合GPU：Designed to fit the NVIDIA® Jetson™ TX2¸ TX2 4GB¸ TX2i and TX1 modules
その他仕様：Dissipates the heat produced by the module through convection
冷却方式：Fin Space: 3.00mm

型番：Heat Sinks
ボードサイズ：87mm x 50mm x 16mm
適合GPU：Designed to fit the NVIDIA® Jetson™ TX2¸ TX2 4GB¸ TX2i and TX1 modules
その他仕様：Dissipates the heat produced by the module through a fan
冷却方式：Fin Space: 3.00mm

型番：Type 7
Interface1：4x USB 2.0 Ports (20-pin T1M header)¸ 4x USB 3.0 Ports (Type-A)
Interface3：10 GbE interconnect: 2x 10GBASE-SR/LR From Dual Inphi CS4223E (Quad SFP+)
ボードサイズ：216mm x 164mm
適合GPU：Combines High-End GPUs with Intel® Xeon® D Server Class and Intel® Atom™ C3000 x86 Processors
その他仕様：GPUs can be targeted for 4 independent display outputs OR for a headless GPGPU processing system using CUDA® cores

仕様書ダウンロード

型番：Type 7
Interface1：4x USB 3.0
Interface3：Dual 10-Gigabit Ethernet
電源電圧： +12V Input
温度範囲： -40℃ to +85℃
ボードサイズ： 125mm x 95mm
その他仕様：Ultra High Speed Storage with M.2 NVMe SSD support

仕様書ダウンロード

型番：Type6
Interface1：3x USB 2.0 (Mini-PCIe)¸ 4x USB 2.0¸ 4x USB 3.0
Interface2：PCI Express x16 Bus Design Access
Interface3：4x GbE Ports with On-Board Magnetics
電源電圧： +12V Input
温度範囲： -40℃ to +85℃
ボードサイズ：125mm x 95mm
その他仕様：Use with Off-the-Shelf or Custom designed breakout boards

仕様書ダウンロード

型番：Type6
Interface1：4x USB 3.0¸ 6x USB 2.0
電源電圧：Single wide input range +16V to +48V DC**** +12V DC input supported in some applications
温度範囲： -40℃ to +85℃
適合GPU：Combines High-End GPUs with latest generation x86 processors in a ruggedized small form factor
その他仕様：GPUs can be targeted for 4 independent display outputs OR for a headless GPU processing system utilizing CUDA® cores
冷却方式：VXG part numbers have Passive Heat Spreaders that are to be installed into a Customer Designed End Thermal Solution

仕様書ダウンロード

型番：Type6
Interface1：8x USB 2.0
Interface2：Mini-PCIe Expansion¸ USB 2.0¸ DisplayPort++
電源電圧：Input: Single +12V input +/- 5% (5mm pitch terminal connector)¸ On-board RTC Battery 3V 48mAh (with option to select from RTC external battery)
温度範囲： -40℃ to +86℃
ボードサイズ：125mm x 95mm
適合GPU：Supports latest Intel® processor sets

仕様書ダウンロード

型番：Type6
Interface1：4x USB 3.0¸ 2x GbE¸ 2x RS-232/485¸ LVDS (2×24)¸ VGA
Interface2：On-Board DisplayPort/HDMI/DVI display switching
Interface3：PCIe/104 Type 1 (CCG018) or PCIe/104 Type 2 (CCG017)
電源電圧： +12V Input
温度範囲： -40℃ to +86℃
ボードサイズ：125mm x 95mm

仕様書ダウンロード

型番：Type6
Interface1：4x USB 2.0¸ 4x USB 3.0
Interface2：PMC/XMC & Mini-PCIe Expansion
電源電圧： +9V to +36V
温度範囲： -40℃ to +86℃
ボードサイズ：381mm x 190.5mm
適合GPU：Supports the latest high performance Intel® processors

仕様書ダウンロード

型番：Type6
Interface1：2x USB 2.0¸ 4x USB 3.0
電源電圧： +12V to +48V DC
ボードサイズ：195mm x 190mm

仕様書ダウンロード

型番：Type6
Interface1：2x USB 2.0¸ 4x USB 3.0
Interface2：Dual PMC/XMC & Mini-PCIe Expansion
Interface3：COM Express® Type 6 compatibility
電源電圧： +12V to +48V DC
温度範囲： -40℃ to +86℃
ボードサイズ：170mm x 165mm
適合GPU：Supports latest Intel® processor sets
その他仕様：Ruggedized¸ locking pin header connectors

仕様書ダウンロード

型番：Type6
Interface1：2x USB 2.0¸ 4x USB 3.0
Interface2：Mini-PCIe Expansion
電源電圧： +12V DC Input Only (DC Barrel)
温度範囲： -40℃ to +86℃
ボードサイズ：125mm x 95mm
適合GPU：Supports latest Intel® processor sets

仕様書ダウンロード

型番：Type6
Interface1：COM Express® Type 2/Type 6 Compatible
Interface2：Supports Compact and Basic COM Express® Modules
Interface3：Bus Connector: COM Express®
温度範囲： -40℃ to +86℃
ボードサイズ：95mm x 125mm

仕様書ダウンロード

型番：Type6
Interface1：PCI Express Lanes (4 lanes)¸SATA (2 channels)¸GBE¸USB (8 ports)
Interface2：SDIO¸LPC Bus¸HD Audio¸LVDS Video¸SPI¸SDVO¸I2C¸SMBus
Interface3：Compatible with all COM Express® Types:Type 2¸ Type 6¸ Type 1¸ Type 10¸ Type 3¸ Type 4¸ Type 5
電源電圧： +12V Input
温度範囲： -40℃ to +86℃
ボードサイズ：125mm x 95mm¸ 95mm x 95mm
その他仕様：Basic and Compact COM Express® Form Factors

仕様書ダウンロード

型番：Type10
Interface1：2 x USB 3.0 Type A¸ 6x USB 2.0¸
Interface2： 2x RS-232¸ 2x GbE¸ 1x mSATA
温度範囲： -40℃ to +86℃
ボードサイズ：84mm x 73.415mm
適合GPU：Support for the latest generation of low-powered CPUs
その他仕様：Combination of PC style and locking pin header connectors

仕様書ダウンロード

型番：Type10
Interface1：2x USB 2.0 (Mini-PCIe)¸ 2x USB 3.0¸ 4x USB 2.0
Interface2：1x high density connector for breakout board utilization
Interface3：Expansion via Mini PCI Express
電源電圧： +12V Input¸ +7.5V to +14V Input Range
温度範囲： -40℃ to +87℃
ボードサイズ：Extremely small size¸84mm x 55mm
その他仕様：Use with off-the-shelf or custom designed breakout boards

仕様書ダウンロード

型番：Type10
Interface1：8x USB 2.0 OR 2x USB 3.0 + 6x USB 3.0
Interface2：Now supporting USB 3.0 on CCG020 model
Interface3：2 x mini PCIe¸ mSATA¸ SATA¸ 2 x GBE¸ 6 x USB¸ LVDS¸ DisplayPort/HDMI/DVI/VGA¸ HD Audio¸ 2 x RS-232/422/485
電源電圧： +6V to +14V
温度範囲： -40℃ to +85℃
ボードサイズ：Extremely small size¸ 84mm x 55mm
適合GPU：Support for the latest generation of low powered CPUs
その他仕様：All ruggedized latching connectors

仕様書ダウンロード

型番：Type2
Interface1：8x USB 2.0 OR 2x USB 3.0 + 6x USB 3.0
Interface2：COM Express® Type 2 Basic and Compact module compatible
Interface3：PCI-104 and PCIe/104 expansion
電源電圧： +6V to +14V
温度範囲： -40℃ to +85℃
ボードサイズ： 84mm x 55mm
その他仕様：COM Express® Carrier Board supports modules from major manufacturers

仕様書ダウンロード

型番：Type2
Interface1：4x USB 2.0
Interface2：Uses any off-the-shelf Qseven module
Interface3：High performance interfaces
form factor：PCI-104 form factor
Install：Install up to 4 PCI-104 boards
電源電圧：Ideal for applications with low power requirements
温度範囲： -20℃ to +70℃
ボードサイズ：Compact size for easy integration
その他仕様：On-board connectors for easy connection to Qseven features

仕様書ダウンロード

型番：Type2
Interface1：4x USB 2.0
Interface2：PCIe/104 form factor
Interface3：Uses any off-the-shelf Qseven module
form factor：High performance interfaces
Install：Compact size for easy integration
電源電圧：Ideal for applications with low power requirements
温度範囲： -20℃ to +70℃
その他仕様：Connectors and cables included for easy connection to Qseven features

仕様書ダウンロード

型番：Type2
Interface1：4x USB 2.0¸ 8x USB 2.0
form factor：ntegrates with any industry standard off-the-shelf Qseven module
電源電圧： +5V 6A¸ +12V 200ma¸ RTC Battery
温度範囲： -40℃ to +85℃
適合GPU：AMD¸ Intel® Atom™ and Freescale i.MX6 options
その他仕様：Optional cable kits available for easy connection to Qseven features

仕様書ダウンロード

型番：Type2
Interface1：1x USB 3.0¸ 4x USB 2.0
Interface2：External SATA/mSATA Switching Circuitry
Interface3：1x microSD
form factor：Quad Serial¸ Dual CAN Bus (Optional)
電源電圧： +12V to +36V DC Input
温度範囲： -40℃ to +85℃
ボードサイズ：146.05mm x 131.76mm
適合GPU：Choose from Intel® E38xxx series¸ Quad¸ Dual or Single core options

仕様書ダウンロード

型番：Type2
Interface1：PCI Express Lanes (4 lanes)¸SATA (2 channels)¸GBE¸USB (8 ports)¸SDIO¸LPC Bus
Interface2：HD Audio¸LVDS Video¸SPI¸SDVO¸I2C¸SMBus
Interface3：Compatible with all COM Express® Types:Type 2¸ Type 6¸ Type 1¸ Type 10¸ Type 3¸ Type 4¸ Type 5
form factor：Basic and Compact COM Express® Form Factors
電源電圧： +12V Input
温度範囲： -40℃ to +85℃
ボードサイズ：125mm x 95mm¸ 95mm x 95mm

仕様書ダウンロード

型番：Type2
Interface1：2x USB 2.0 (exposed)¸ 2x USB 2.0 (Mini-PCIe)¸ 2x USB 3.0
Interface2：Feature Packed (HDMI¸ SATA¸ 2x MIPI CSI-2 Camera Interfaces)
Interface3：2x USB 3.0¸ 2x USB 2.0¸ 2x USB 2.0 to miniPCIe
form factor：Extremely Small Form Factor
電源電圧： +5V DC Input only (fine pitch¸ high current)
温度範囲： -40℃ to +85℃
ボードサイズ：105.8mm x 82.4mm

仕様書ダウンロード

型番：Type2
Interface1：2x USB 2.0
Interface3：1x microSD
電源電圧： +6V to +36V DC Input
温度範囲： -40℃ to +85℃
ボードサイズ：100mm x 57.5mm

仕様書ダウンロード

型番：Type2
Interface1：Up to three USB 2.0 (Hi-Speed) ports¸ Up to two USB 3.0 (SuperSpeed) ports
Interface2：The onboard PCIe Gen 3.0 switch supports two x4 port dataplane connections
電源電圧： +12V Input¸ 3V3_AUX (VS2 is not used)¸ 5V (VS3)
温度範囲： -40℃ to +85℃
適合GPU：1 TFLOP¸ 256 CUDA cores with NVIDIA® Pascal™ or Maxwell™ GPU Architecture
その他仕様：Can be used with RTG004 Graphite VPX CPU TX2/TX1 RTM to aid in development
冷却方式：Conduction cooled

仕様書ダウンロード

型番：Type2
Interface1：Up to eight USB 2.0 (Hi-Speed) ports¸ Up to two USB 3.0 (SuperSpeed) ports
Interface2：Two x4 PCIe Gen3 Ports¸ Three 10/100/1000 BASE-T ports¸ Two 1000 BASE-X ports¸ Two USB 3.0 (SuperSpeed) ports¸ Eight USB 2.0 (Hi-Speed) ports¸ Two SATA 2.0 Ports¸ O
Interface3：4x GP Inputs¸ 4x GP Outputs
form factor：Supports 3U VPX profiles: MOD3 PAY 2F2T-16.2.5-2¸3 and MOD3-PAY-2F2U-16.2.3-2¸3
温度範囲： -40℃ to +85℃
適合GPU：Intel® Atom™ E3845 (Bay Trail) Quad Core processor
その他仕様：3U OpenVPX VITA65

仕様書ダウンロード

型番：Type2
Interface1：The onboard PCIe Gen 3.0 switch supports multiple Dataplane options: one x8 or two x4 ports with NT capabilities
Interface2：I/O supports up to 4 DisplayPort outputs or 2 DVI outputs
電源電圧：12V (VS1)¸ 3.3V (VS2)¸ and 5V (VS3)
適合GPU：NVIDIA® GeForce GTX 950M/2GB GDDR5
冷却方式：Conduction Cooled only

仕様書ダウンロード

型番：Type2
Interface1：The onboard PCIe Gen 3.0 switch supports multiple Dataplane options: one x8 or two x4 ports
Interface2：I/O options: PMC I/O p64s or XMC I/O x12d+x8d+x38s
電源電圧：12V (VS1)¸ 3.3V (VS2)¸ and 5V (VS3)
温度範囲： -40℃ to +85℃
冷却方式：Conduction cooled or Air cooled options available

型番：Type2
Interface1：20 x GbE (10/100/1000 Ethernet) Ports – 16 to VPX backplane¸ 4 to front panel IO
Interface2：Carrier Grade Ethernet Switching
Interface3：Available with RJ-45 Front panel for easy interfacing
form factor：Supports 3U OpenVPX profile: MOD3-SWH-16T-16.4.7-1
電源電圧：23W Max
温度範囲： -40℃ to +85℃
ボードサイズ：1” Pitch VITA 65 Compliant 3U VPX form factor. L x W = 160mm x 100mm
その他仕様：Web GUI or CLI Management
冷却方式：Conduction cooled or Air cooled Heatsink option

仕様書ダウンロード

型番：Type2
Interface1：PCI-Express x1 Lane or USB-2 Host Bus Interface
Interface2：2 ports individually isolated or non-
Interface3：Switchable RS-232/422/485
form factor：Bi-directional data speeds up to 20Mbps (optional) (RS-422/485)
Install：Port settings can be set up by sofware (on certain models)
温度範囲： -40℃ to +85℃
ボードサイズ：50.95 mm x 30 mm¸ Mini PCIe “Full”
その他仕様：Supports full duplex (4 wire)¸ half duplex (2 wire) with auto TxD echo cancellation modes in RS-422/485

仕様書ダウンロード

型番：Type2
Interface1：Mini PCI Express
Interface2：16 ADC input channels
form factor：500kSPS
Install：16-bit resolution
温度範囲： -40℃ to +85℃
ボードサイズ：50.95 mm x 30 mm¸ Mini PCIe “Full”

仕様書ダウンロード

型番：Type2
Interface1：1x USB 2.0, ADG077: 4-Port Hub, Oversize Mini PCIe Module, PCI-104 (Pass Through), SIM Socket, Type 1 or Type 2 PCIe/104
Interface2：PCIe/104 Compliant
Interface3：On-Board USB Switching
電源電圧：+5V (PCIe/104 Bus Supplied)
温度範囲：-40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：Type2
Interface1：External Battery input¸ External Interrupt input¸ Forward/Reverse and Wheeltick inputs for Automotive Dead Reckoning¸ TIMEPULSE output syncronized with GPS time grid
Interface2：Used in any Mini PCIe socket that supports USB
Install：Compatibility with Windows & Linux operating systems
温度範囲： -40℃ to +85℃
ボードサイズ：50.95 mm x 30 mm¸ Mini PCIe “Full”
その他仕様：Easily integrated into a wide array of new and existing systems

仕様書ダウンロード

型番：Type2
Interface1：PCI-104
Interface2：Power is drawn from the PCI-104 Bus connector
Interface3：SIM card support
form factor：Half-Mini and Full-Mini PCIe cards supported
Install：Three mini-PCIe status LEDs
電源電圧： +5V No modules installed 50mA.1 module using peak power up to 2200mA
温度範囲： -40℃ to +85℃
ボードサイズ：90.2mm x 96mm
その他仕様：Optional PCI Express Mini-Card Specification Revision 2.0 which adds a DisplayPort connection

仕様書ダウンロード

型番：Type2
Interface1：PCIe/104 Type 1 or Type 2
Interface2：Mini-PCIe status LEDs
Interface3：SIM card support
Install：Power is drawn from the PCIe/104 bus connector
電源電圧：PC/104-Express Stack+5V from PCIe/104 or PCI/104 Express stack
温度範囲： -40℃ to +85℃
ボードサイズ：Length: 9.02 cm/3.55” Width: 9.6 cm/3.7″
その他仕様：USB client connectors for Mini-PCIe USB connections

仕様書ダウンロード

型番：Type2
Interface1：Supports up to four Mini PCIe modules simultaneously
Interface2：Supports any Mini PCIe/mSATA product
Interface3：Maximum flexibility keeping the PCIe/104 stack small
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm (3.775″ x 3.550″)¸ Fully PCIe/104 compliant

仕様書ダウンロード

型番：Type2
Interface1：MPG101: Mini Tek 2mm 2×5 Right Angle¸ MPG102: Mini Tek 2mm 2×5 Vertical¸ MPG104: 2x Mini Tek 2mm 2×5 Vertical
Interface2：Ideal for adding extra Ethernet capabilities to any system with minimal increase in overall system size
Interface3：Used in any Mini PCIe socket that supports PCIe
form factor：Easily integrated into a wide array of new and existing systems
温度範囲： -40℃ to +85℃
ボードサイズ：50.95 mm x 30 mm¸ Mini PCIe “Full”
その他仕様：Compatibility with a large variety of popular operating systems

仕様書ダウンロード

型番：Type2
Interface1：External Battery input¸ External Interrupt input¸ Forward/Reverse and Wheeltick inputs for Automotive Dead Reckoning¸ TIMEPULSE output syncronized with GPS time grid
Interface2：Provides global positioning and time-stamp information
form factor：Uses little space and power within a system
Install：Easily integrated into any existing system
温度範囲： -40℃ to +85℃
ボードサイズ：42 mm x 22 mm (M.2 Type-2242-S3-B)

仕様書ダウンロード

型番：Type2
Interface1：Additional connectors include 2 SIM card slots for cellular applications and 2 wireless status signal headers to aid with integration in custom enclosures
Interface2：Wireless disable switches
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：Type2
電源電圧：12V (VS1)¸ 3.3V (VS2)¸ and 5V (VS3)
温度範囲： -40℃ to +85℃
冷却方式：Conduction cooled or Air cooled options available

仕様書ダウンロード

型番：Type2
Interface1：PCI-104 and PC/104-Plus compatible (mechanically configured for mounting PMC cards)
Interface2：PCI-104 120-pin stack-through connectors
Interface3：Two 64 pin passive PMC connectors
form factor：Slot selector switch for PCI-104¸ “slot assigned”
温度範囲： -40℃ to +85℃
ボードサイズ：Measures 6.526” long by 3.550” high

仕様書ダウンロード

型番：Type2
Interface1：CIe/104 and PCI/104-Express compatible
Interface2：XMC to PCIe ConnectionPMC to PCI Connection
Interface3：Connector: XMC¸ PMC¸ PCIe (x16 Card accepted¸ x8 Compatible)¸ PCI (32-bit)
form factor：BUSMODE LEDs with Jumper Selection for Testing
電源電圧： -12V¸ +12V¸ +3V¸ +5V¸ All power supplied by connected PMC/XMC Carrier
温度範囲： -40℃ to +85℃
ボードサイズ：149mm x 74mm

仕様書ダウンロード

型番：Type2
Interface1：4x USB 2.0¸ 4x USB 3.0
Interface2：PMC/XMC & Mini-PCIe Expansion
Interface3：COM Express® Type 6 Compatibility
form factor：Fits 1U Rack Mount Chassis
電源電圧： +9V to +36V
温度範囲： -40℃ to +85℃
ボードサイズ：381mm x 190.5mm
適合GPU：Supports the latest high performance Intel® processors

仕様書ダウンロード

型番：Type2
Interface1：2x USB 2.0¸ 4x USB 3.0
Interface2：Ruggedized¸ locking pin header connectors
Interface3：Dual PMC/XMC & Mini-PCIe Expansion
form factor：COM Express Type 6 compatibility
電源電圧： +12V to +48V DC
ボードサイズ：195mm x 190mm
適合GPU：Supports latest Intel® processor sets

仕様書ダウンロード

型番：Type2
Interface1：2x USB 2.0¸ 4x USB 3.0
Interface2：Dual PMC/XMC & Mini-PCIe Expansion
Interface3：COM Express® Type 6 compatibility
form factor：Ruggedized¸ locking pin header connectors
電源電圧： +12V to +48V DC
温度範囲： -40℃ to +85℃
ボードサイズ：" 170mm x 165mm"
適合GPU：Supports latest Intel® processor sets

仕様書ダウンロード

型番：PCI/104 - Express
Interface1：x1 lane PCI Express card edge allows installation in any slot width
Interface2：PCIe/104 and PCI/104-Express compatible
Interface3：PCIe/104 156-pin connector
form factor：PCI-104 120-pin connector
電源電圧：+5V input for PCIe/104 add-in card
温度範囲： -40℃ to +85℃
その他仕様：x1 lane PCI Express card edge allows installation in any slot width

仕様書ダウンロード

型番：PCI/104 - Express
Interface1：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
Interface2：PCIe/104 and PCI/104-Express compatible
Interface3：PCIe/104 156-pin top connector
form factor：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
温度範囲： -40℃ to +85℃
ボードサイズ：193mm x 152mm
その他仕様：Custom support bracket to ensure PCIe card stability

仕様書ダウンロード

型番：PCI/104 - Express
Interface1：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
Interface2：PCIe/104 and PCI/104-Express compatible
Interface3：PCIe/104 156 pin bottom connector
form factor：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm
その他仕様：Custom support bracket to ensure PCIe card stability

仕様書ダウンロード

型番：PCI/104 - Express
Interface1：SATA signals from any PCIe/104 or PCI/104-Express Type 2 SBC eliminates the need for SATA cables
Interface2：Storage capacity range from 4GB to +256GB
Interface3：Supports up to two mSATA SSD Modules
電源電圧： +3.3V / 0.5A maximum¸ Low Power Consumption: 260mA (Active) / 130 mA (Idle)¸ PCI-104 Bus¸ PCIe/104 Bus
温度範囲： -40℃ to +85℃
ボードサイズ：mSATA SSD Module: 2.000″ x 1.175″ (50.80mm x 29.85mm)¸ JEDEC 300-MB Compliant¸ Mini PCIe Form Factor Compliant¸ SSD/104 Carrier: 3.550″ x 3.775″ (90.17mm x 95.89mm)¸ PC/104 Com

仕様書ダウンロード

型番：PCI/104 - Express
Interface1：PCI/104-Express form factor RS-232/422/485 add-in card
Interface3：One octal PCI Express UART with up to 128 byte transmit and receive FIFO buffers
電源電圧： +5V DC @ 100mA (typical)¸ 650mA (max)
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PCIe/104
Interface1：PCIe/104 and PCI/104-Express compatible
Interface2：PCIe/104 and PCI/104-Express compatible
Interface3：PCIe/104 156-pin connector
form factor：PCI-104 120-pin connector
電源電圧： +5V input for PCIe/104 add-in card
温度範囲： -40℃ to +85℃
ボードサイズ：4.375″ x 4.050″
その他仕様：x1 lane PCI Express card edge allows installation in any slot width

仕様書ダウンロード

型番：PCIe/104
Interface1：Power is drawn from the PCIe/104 bus connector
Interface2：SIM card support
電源電圧： +5V from PCIe/104 or PCI/104 Express stack
温度範囲： -40℃ to +85℃
ボードサイズ：Length: 9.02 cm/3.55” Width: 9.6 cm/3.7″
適合GPU：Mini-PCIe status LEDs
その他仕様：USB client connectors for Mini-PCIe USB connections

仕様書ダウンロード

型番：PCIe/104
Interface1：CIe/104 and PCI/104-Express compatible
Interface2：XMC to PCIe ConnectionPMC to PCI Connection
Interface3：Connector: XMC¸ PMC¸ PCIe (x16 Card accepted¸ x8 Compatible)¸ PCI (32-bit)
form factor：BUSMODE LEDs with Jumper Selection for Testing
電源電圧： -12V¸ +12V¸ +3V¸ +5V¸ All power supplied by connected PMC/XMC Carrier
温度範囲： -40℃ to +85℃
ボードサイズ：149mm x 74mm

仕様書ダウンロード

型番：PCIe/104
Interface1：Expand the height clearance between Single Board Computers (SBCs) and PCIe/104 or PCI/104-Express Peripheral
Interface2：PCIe/104 (PC/104-Express)
Interface3：Electrical Interface: PC/104-Express
form factor：Bus Connectors: PCIe/104 x 16
温度範囲： -40℃ to +85℃
ボードサイズ：Length: 90.2mm/3.55” Height: 14.605mm/0.575”

仕様書ダウンロード

型番：PCIe/104
Interface1：Source: PCIe/104 BusOnboard power supply for Mini PCIe sockets
Interface2：Supports any Mini PCIe/mSATA product
Interface3：Maximum flexibility keeping the PCIe/104 stack small
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PCIe/104
Interface1：4 x PCIe x1 lanes
Interface2：On-board connectors for instant access to:
form factor：PCIe/104 form factor
温度範囲： -40℃ to +85℃
ボードサイズ：Fully PCI/104 compliant
適合GPU：Intel & ARM based processors:

仕様書ダウンロード

型番：PCIe/104
Interface1：Source: PCIe/104 BusOnboard power supply for Mini PCIe sockets
Interface2：Additional connectors include 2 SIM card slots for cellular applications and 2 wireless status signal headers to aid with integration in custom enclosures
Interface3：Wireless disable switches
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PCIe/104
Interface1：All PCIe/104 lanes direct connect to PCI Express lanes
Interface2：PCIe/104 and PCI/104-Express compatible
Interface3：PCIe/104 156-pin top connector
form factor：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
Install：Custom support bracket to ensure PCIe card stability
温度範囲： -40℃ to +86℃
ボードサイズ：193mm x 152mm

仕様書ダウンロード

型番：PCIe/104
Interface1：All PCIe/104 lanes direct connect to PCI Express lanes
Interface2：PCIe/104 and PCI/104-Express compatible
Interface3：PCIe/104 156 pin bottom connector
form factor：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
Install：Custom support bracket to ensure PCIe card stability
温度範囲： -40℃ to +87℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PCIe/104
Interface1：Compatible with PCIe/104 and PCI/104-Express
温度範囲： -20℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PCIe/104
Interface1：All PCIe/104 signals connected
Interface2：Use of PCI-104 Boards in PCIe/104 Stack
Interface3：Up/Down Stack Compatible
form factor：PCIe/104 Compliant
電源電圧： +3.3V DC¸ Transfers: +12V and +5V
温度範囲： -40℃ to +84℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PCIe/104
Interface1：Supports all SATA generations:SATA I – 1.5Gbps 150MB/sSATA II – 3Gbps 300MB/sSATA III – 6Gbps 600MB/s
Interface2：Use any 2.5” Hard Drive
Interface3：Up to 2 TB of Storage
form factor：Supports SATA III
電源電圧： +5V/3A maximum¸ Onboard power supply for 3.3v drives¸ PCIe/104 Bus
温度範囲： -40℃ to +85℃
ボードサイズ：112.27mm x 95.89mm

仕様書ダウンロード

型番：PCIe/104
Interface1：Supports all SATA generations:• SATA I – 1.5Gbps 150MB/s• SATA II – 3Gbps 300MB/s• SATA III – 6Gbps 600MB/s
Interface2：Storage capacity range from 4GB to +256GB
Interface3：Supports up to two mSATA SSD Modules
form factor：SATA signals from any PCIe/104 or PCI/104-Express Type 2 SBC eliminates the need for SATA cables
電源電圧： +3.3V / 0.5A maximum¸ Low Power Consumption: 260mA (Active) / 130 mA (Idle)¸ PCI-104 Bus¸ PCIe/104 Bus
温度範囲： -40℃ to +86℃

仕様書ダウンロード

型番：PCIe/104
Interface1：2 x USB (from SUMIT) via Mini USB connectors
Interface2：Compatible with Type-1 or Type-2 SUMIT-104 systems
Interface3：Access to additional auxiliary SUMIT-104 signals
form factor：Bus Connectors: SUMIT A and B¸ PCIe/104 x 1
Install：Optional: 2 x USB (from SUMIT) via Mini USB connectors
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PCIe/104
Interface1：Type 1 PCIe/104 & XMC Connectors
Interface2：PCIe/104 Compliant
電源電圧： +5V over PCIe/104
温度範囲： -40℃ to +85℃
ボードサイズ：96.018mm x 152.4mm

仕様書ダウンロード

型番：PCIe/104
Interface1：32 single ended / 16 differential analog inputs with 16-bit resolution¸ 500ksps sampling rate and a wide input voltage range up to ±10V
Interface2：16-bit bi-directional digital I/O with selectable voltage ranges
Interface3：4 analog output channels with 16-bit resolution and a wide output voltage range up to ±10.24V
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 compliant: 3.775″ x 3.550″

仕様書ダウンロード

型番：PCIe/104
Interface1：Four or eight switchable RS-232/422/485 ports
Interface2：PCIe/104 form factor
Interface3：Four or eight switchable RS-232/422/485 ports
form factor：3 kV optical isolation on each port
Install：Rugged filtering on all ports for immunity to EMI and noise
電源電圧： +5V DC @ 500mA (typ)¸ 1A (max)
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm
その他仕様：Configurable tri-state on power up in RS-422/485 mode

仕様書ダウンロード

型番：PCIe/104
Interface1：4x Dual-Mode Mini DisplayPort Connections
Interface2：Supports OpenGL/OpenCL Technology
Interface3：PCIe x1 Up/Down stack compatible
form factor：PCIe x16 Down stack compatible
Install：PCIe x16 Up stack available
電源電圧： +12V (Max wattage dependent upon selected module)¸ +5V
温度範囲： -10℃ to +70℃ ¸ -40℃ to +70℃
ボードサイズ：95.89mm x 107.95mm x 15.55mm
その他仕様：Supports Microsoft® DirectX® 11 Technology

仕様書ダウンロード

型番：PCIe/104
Interface1：1x PCIe
Interface2：Up to Four Video Connections
Interface3：Supports Microsoft® DirectX® 11 Technology
form factor：Supports OpenGL/OpenCL Technology
Install：PCIe x1 Down Stack Compatible
電源電圧：PCIe x16 Down Stack Compatible
ボードサイズ：95.89mm x 107.95mm x 15.55mm
その他仕様：PCIe x1 Down Stack Compatible

仕様書ダウンロード

型番：PCIe/104
Interface1：Up to Four Video Connections
Interface2：Supports Microsoft® DirectX® 11 Technology
Interface3：Supports OpenGL/OpenCL Technology
form factor：PCIe x1 Up Stack Compatible
Install：PCIe x16 Up Stack Compatible
電源電圧： +12V Input¸ +3.3V @ 4A¸ +5V
ボードサイズ：101.73mm x 95.88mm

仕様書ダウンロード

型番：PCIe/104
Interface1：Single x8 PCIe configuration
Interface2：10GbE Connectivity
Interface3：Powered by Intel’s X710 Ethernet Controller
form factor：LAN and SAN flexibility
温度範囲： 0℃ to +55℃
ボードサイズ：PC/104 compliant: 3.775″ x 3.550″
その他仕様：Provides support for network and server virtualization

仕様書ダウンロード

型番：PCIe/104
Interface1：4x USB 2.0
Interface2：Uses any off-the-shelf Qseven module
Interface3：High performance interfaces
form factor：PCIe/104 form factor
Install：Connectors and cables included for easy connection to Qseven features
温度範囲： -20℃ to +70℃
その他仕様：Ideal for applications with low power requirements

仕様書ダウンロード

型番：PCIe/104
Interface1：4x USB 3.0¸ 2x GbE¸ 2x RS-232/485¸ LVDS (2×24)¸ VGA
Interface2：On-Board DisplayPort/HDMI/DVI display switching
Interface3：PCIe/104 Type 1 (CCG018) or PCIe/104 Type 2 (CCG017)
電源電圧： +12V Input
温度範囲： -40℃ to +84℃
ボードサイズ：125mm x 95mm

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：2 ports
Interface2：Bus Interface: PC/104-Plus
Interface3：CAN Controller: Two NXP SJA1000 CAN controllers
form factor：Decoded Address Range: Configurable for BasicCAN and PeliCAN
電源電圧： +5V
温度範囲： -40℃ to +85℃
ボードサイズ：Fully PCI/104 compliant

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Mini PCI Type III 124 pin female socket
Interface2：PC/104-Plus 120 pin stack-through connector
Interface3：PC/104 64 and 40 pin passive stack-through connectors
form factor：Compatible with standard Universal¸ 3.3V or 5V PC/104-Plus stack
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 compliant: 3.775″ x 3.550″
その他仕様：3.3V regulator capable of delivering 2 Watts of power to the Mini PCI card

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Connectors/Interfaces include a PCI-104 120 pin stack-through connector with shroud for connection to the host CPU board and PC/104 64 and 40 pin passive stack-through connecto
Interface2：+5V input for PCIe/104 add-in card
温度範囲： -40℃ to +85℃
ボードサイズ：4.913“ wide by 4.200” high

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Supports all SATA generations:• SATA I – 1.5Gbps 150MB/s• SATA II – 3Gbps 300MB/s• SATA III – 6Gbps 600MB/s
Interface2：SATA signals from any PCIe/104 or PCI/104-Express Type 2 SBC eliminates the need for SATA cables
Interface3：Supports up to two mSATA SSD Modules
form factor：Storage capacity range from 4GB to +256GB
電源電圧： +3.3V / 0.5A maximum¸ Low Power Consumption: 260mA (Active) / 130 mA (Idle)¸ PCI-104 Bus¸ PCIe/104 Bus
温度範囲： -40℃ to +86℃

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Supports all SATA generations:• SATA I – 1.5Gbps 150MB/s• SATA II – 3Gbps 300MB/s• SATA III – 6Gbps 600MB/s
Interface2：Storage capacity range from 4GB to +256GB
Interface3：SATA signals from any PCIe/104 or PCI/104-Express Type 2 SBC eliminates the need for SATA cables
form factor：Supports up to two mSATA SSD Modules
電源電圧： +3.3V / 0.5A maximum¸ Low Power Consumption: 260mA (Active) / 130 mA (Idle)¸ PCI-104 Bus¸ PCIe/104 Bus
温度範囲： -40℃ to +85℃
ボードサイズ：mSATA SSD Module: 2.000″ x 1.175″ (50.80mm x 29.85mm)¸ JEDEC 300-MB Compliant¸ Mini PCIe Form Factor Compliant¸ SSD/104 Carrier: 3.550″ x 3.775″ (90.17mm x 95.89mm)¸ PC/104 Com

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：2¸ 4 or 8 asynchronous serial ports. 2 and 4 ports available in dedicated RS-423¸ 4/8 ports available in switchable RS-232/422/485 and now¸ 8 ports in switchable RS-232/422/485/TTL.
Interface2：Speed: Data transfer speeds range from 50 bps to 1.8432 Mbps.
Interface3：Each port is controlled by a high performance UART¸ providing 64 bytes of transmit and receive FIFO buffers.
電源電圧： +5V DC @ 500mA (typ)¸ VI/O of +5V or 3.3V DC
温度範囲： -40℃ to +85℃
ボードサイズ：Fully PC/104-Plus compliant¸ PC/104 Compliant
その他仕様：Adaptability: Supports three RS-485 modes: Full Duplex¸ Half Duplex and Multi-drop. (TTL models supports Full Duplex only.)

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：16 RS-232/422/485 serial ports
Interface2：Speed: Data rates up to 1.0Mbps RS-232 and 4.16Mbps RS-422/485
Interface3： Each port is controlled by a high performance UART¸ with 64 bytes of transmit and receive FIFO buffers
電源電圧： +5V 400mA max¸ VI/O of +5V or 3.3V DC
温度範囲： -40℃ to +85℃
ボードサイズ：Fully PC/104-Plus compliant
その他仕様：Adaptability: Jumper selectable RS-485 Bias and Termination resistors

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：2 or 4 asynchronous serial ports available in switchable RS-232/422/485
Interface2：Speed: Data transfer speeds range from 50 bps to 1.8432 Mbps
Interface3：Each port is controlled by a high performance UART¸ providing 64 bytes of transmit and receive FIFO buffers
電源電圧： +5V DC 500mA (max.)VI/O of +5V or +3.3V DC
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 Compliant
その他仕様：Adaptability: Supports three RS-485 modes: full duplex¸ half duplex and multi-drop

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：2 synchronous/asynchronous serial ports
Interface2：Flexibility: Choice of seven software programmable electrical interfaces (RS-232¸ RS-422¸ RS-449¸ EIA-530¸ EIA-530A¸ V.35 and X.21).
Interface3：Speed: Achieve rapid data transfer rates up to 18.432 Mbps per channel.
form factor：USART: Two dual channel Zilog Z16C32 Integrated Universal Serial Controllers (IUSCs) with 32 byte transmit and receive.
電源電圧： +5V DC 1.0 A (max.)
温度範囲： -40℃ to +125℃
ボードサイズ：Fully PCI/104 compliant
その他仕様：Protocols: SDLC¸ HDLC¸ MonoSync¸ Transparent BiSync¸ Async¸ external character sync and others.

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Two synchronous/asynchronous serial channels
Interface2：Multiple communication protocols supported: RS 232¸ RS-422¸ RS-485¸ HDLC¸ SDLC¸ MonoSync¸ BiSync and Async
電源電圧： +5V DC @ 200 to 400 mA (typ)
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 Compliant

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Power is drawn from the PCI-104 Bus connector
Interface2：SIM card support
Interface3：Half-Mini and Full-Mini PCIe cards supported
form factor：Three mini-PCIe status LEDs
Install：Adapter supplies 3.3V and 1.5V DC power to the Mini-PCIe card
電源電圧： +5V No modules installed 50mA.1 module using peak power up to 2200mA
温度範囲： -40℃ to +86℃
ボードサイズ：90.2mm x 96mm
その他仕様：Optional PCI Express Mini-Card Specification Revision 2.0 which adds a DisplayPort connection

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Converts transactions on the PCI-104 bus to PC/104 bus transactions (PCI to ISA)
Interface2：Acts as a PCI target on the PCI-104 host system¸ and as the ISA host on the PC/104 bus
Interface3：16-bit bidirectional I/O (optional)Input/Output Ranges: Hardware selectable +3.3V or +5V (TTL/CMOS)High Current: 24mA
form factor：Maps PCI address space to ISA address space through base address registers
Install：Fully customizable IO and memory address ranges¸ loaded at system start-up via on-board EEPROM interface
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm (3.775″ x 3.550″)¸ Fully PCI/104 compliant
その他仕様：Supports 8 and 16-bit memory and I/O data transfers on the ISA bus

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：PCI-104 and PC/104-Plus compatible (mechanically configured for mounting PMC cards)
Interface2：PCI-104 120-pin stack-through connectors
Interface3：Two 64 pin passive PMC connectors
form factor：Slot selector switch for PCI-104¸ “slot assigned”
Install：Mounting and voltage-keying holes for PMC card
温度範囲： -40℃ to +86℃
ボードサイズ：6.526” long by 3.550” high

型番：PC/104 - Plus
Interface1：Use of PCI-104 Boards in PCIe/104 Stack
Interface2：Up/Down Stack Compatible
Interface3：PCIe/104 Compliant
電源電圧： +3.3V DC¸ Transfers: +12V and +5V
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm (3.775″ x 3.550″)¸ Fully PCIe/104 compliant

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：Supports all SATA generations:• SATA I – 1.5Gbps 150MB/s• SATA II – 3Gbps 300MB/s• SATA III – 6Gbps 600MB/s
Interface2：Supports up to two mSATA SSD Modules
Interface3：SATA signals from any PCIe/104 or PCI/104-Express Type 2 SBC eliminates the need for SATA cables
form factor：Storage capacity range from 4GB to +256GB
電源電圧： +3.3V / 0.5A maximum¸ Low Power Consumption: 260mA (Active) / 130 mA (Idle)¸ PCI-104 Bus¸ PCIe/104 Bus
温度範囲： -40℃ to +86℃

型番：PC/104 - Plus
Interface1：32 single ended / 16 differential analog inputs with 16-bit resolution¸ 100ksps sampling rate and a wide input voltage range up to ±10V
Interface2：16-bit bi-directional digital I/O with selectable voltage ranges
Interface3：4 analog output channels with 16-bit resolution and a wide output voltage range up to ±10V
form factor：PCI-104 and PC/104-Plus options
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 compliant: 3.775″ x 3.550″
その他仕様：Built-in temperature auto-calibration

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：12 RS-232/422/485 optically isolated serial ports
Interface2：Speed: Data rates up to 1 Mbps RS-232 and 4.16 Mbps RS-422/485
Interface3：Each port is controlled by a high performance UART¸ providing 64 bytes of transmit and receive FIFO buffers
form factor：Adaptability: Supports full duplex (4-wire) half duplex (2-wire) and multi-drop (4-wire) in RS-422/485 mode
電源電圧： +3.3V DC¸ Transfers: +12V and +5V
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm (3.775″ x 3.550″)¸ Fully PCIe/104 compliant

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：PCI-104 form factor
Interface2：Up to 4 PCI-104 devices
Interface3：On-board connectors for instant access to SATA¸ Ethernet¸ USB¸ LVDS & VGA Video¸ and 2x RS-232 & 2x RS-422/485
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 Compliant
適合GPU：AMD G-Series、Intel Atom、Freescale、NVIDIA、Texas Instruments、VIA

仕様書ダウンロード

型番：PC/104 - Plus
Interface1：4x USB 2.0
Interface2：PCI-104 form factor
Interface3：Install up to 4 PCI-104 boards
form factor：Uses any off-the-shelf Qseven module
Install：Compact size for easy integration
温度範囲： -20℃ to +70℃
その他仕様：On-board connectors for easy connection to Qseven features

仕様書ダウンロード

型番：PC/104
Interface1：2 ports
Interface2：Bus Interface: PC/104
Interface3：Optional: DB-9¸ standard: 10-pin¸ right angled header (+5V power output)
form factor：Decoded Address Range: Configurable for BasicCAN and PeliCAN
電源電圧： +5V
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 Compliant
その他仕様：CAN Controller: Two NXP SJA1000 CAN controllers

仕様書ダウンロード

型番：PC/104
Interface1：Choice of seven software programmable electrical interfaces (RS-232¸ RS-422¸ RS-449¸ EIA-530¸ EIA-530/A¸ V.35 and X.21).
Interface2：Speed: Achieve rapid data transfer rates up to 4.9 Mbps per channel.
Interface3：Supports four software programmable DMA channels¸ and offers programmable bit rates with different oscillators available for custom bit rates. Also supports a wide range of third party applicati
電源電圧： +5V DC @ 190 to 660 mA (typ)
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 Compliant
適合GPU：Performance: A 20 MHz Zilog 85230 ESCC controls each channel.

仕様書ダウンロード

型番：PC/104
Interface1：PC/104 64 and 40-pin passive stack-through connectors
form factor：Breadboarding area for electrical circuit assembly and testing
温度範囲： -30℃ to +65℃
ボードサイズ：6.145″ long by 4.200″ high
その他仕様：Reset button

仕様書ダウンロード

型番：PC/104
Interface1：16-bit bidirectional I/O (optional)
Interface2：Compatible with all SMART battery chargers
Interface3：Easily integrates SMART batteryinto a PC/104 Stack
form factor：Connectors: SMART Battery connector (5787428-1)¸ 5 pin Terminal header and plug
電源電圧： +3.3V or +5V DW7
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PC/104
Interface1：Compatible with all SMART battery chargers
Interface2：Easily integrates SMART batteryinto a PC/104 Stack
Interface3：Connectors: SMART Battery connector (5787428-1)¸ 5 pin Terminal header and plug
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：PC/104
Interface1：4 or 8 asynchronous¸ jumper selectable RS-232 or RS-422/485 serial ports.
Interface2：Speed: Data transfer speeds range from 50 bps to 460.8 Kbps.
Interface3：Each port is controlled by a high performance quad UART¸ providing 64 bytes of transmit and receive FIFO buffers.
電源電圧： +5V DC @ 100mA (max)
温度範囲： -40℃ to +85℃
ボードサイズ：96mm x 104.1mm x 11.2mm
その他仕様：Adaptability: Supports two RS-485 modes: Full Duplex and Half Duplex with TxD echo cancellation.

仕様書ダウンロード

型番：PC/104
Interface1：16C2850 dual UARTs control each port¸ providing 128 bytes of TxD/RxD FIFO buffers
Interface2：High Density Design: Eight switchable RS-232/422/485 ports and four dedicated RS-232 ports on one small¸ PC/104 footprint
Interface3：Support for all three RS-485 modes: full duplex¸ half duplex and multi-drop
form factor：Performance: 16C2850 dual UARTs control each port¸ providing 128 bytes of TxD/RxD FIFO buffers
電源電圧： +5V DC @ 500mA (typ)¸ 1A (max)
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 compliant: 3.775″ x 3.550″
その他仕様：Speed: Data rates up to 460.8 Kbps (RS-422/485) and 115.2 Kbps (RS-232)

仕様書ダウンロード

型番：PC/104
Interface1：Two or four RS-232 or RS-422/485 serial ports
Interface2：Protection: Ports are individually optically isolated at 3.0 kV AC* (most models) peak to peak
Interface3： Ports controlled by a high performance dual UART¸ which is backward compatible with standard 16450 and 16550 UARTs.
form factor：Speed: Data rates up to 460.8 Kbps
電源電圧： +5V DC @ 260mA (typ)
温度範囲： -40℃ to +85℃
ボードサイズ：96mm x 104.1mm x 11.2mm
その他仕様：Performance: Ports controlled by a high performance dual UART¸ which is backward compatible with standard 16450 and 16550 UARTs.

仕様書ダウンロード

型番：PC/104
Interface1：One available PC/104 module stack connector
Interface3：Indoor: 450 to 900′Outdoor: 3000′ with dipole antenna¸ >5 miles with gain antenna
電源電圧： +5V DC¸ powered via PC/104 bus¸ 630 mA Max
温度範囲： -40℃ to +150℃
ボードサイズ：91mm x 97mm x 11mm

仕様書ダウンロード

型番：PC/104
Interface1：One available PC/104 module stack connector
Interface3： Indoor: 450-900 feet. Outdoor: 3000 feet with dipole antenna¸ over 6 miles with gain antenna
電源電圧： +5V DC¸ powered via PC/104 bus¸ 630 mA Max
温度範囲： -40℃ to +150℃
ボードサイズ：91mm x 97mm x 11mm

仕様書ダウンロード

型番：PC/104
Interface1：One available PC/104 module stack connector
Interface3：Indoor: 1000’+Outdoor: >20 miles with omni-directional antenna
電源電圧： +5V DC¸ powered via PC/104 bus¸ 630 mA Max
温度範囲： -40℃ to +150℃
ボードサイズ：91mm x 97mm x 11mm

仕様書ダウンロード

型番：PC/104
Interface1：Four or eight asynchronous¸ jumper selectable RS-232 ports
Interface2：Speed: Supports data communications speeds up to 230.4 Kbps
Interface3：State of the art UARTs control each port¸ providing 64 bytes of transmit and receive FIFO buffers.
電源電圧： +5V DC @ 100mA (max)
温度範囲： -40℃ to +150℃
ボードサイズ：96mm x 104.1mm x 11.2mm
その他仕様：Easy Installation: Ready for simple installation¸ each board arrives complete with driver software and a comprehensive manual.

仕様書ダウンロード

型番：PC/104
Interface1：1x USB 2.0
Interface2：All-in-one PC/104 communication solution for CANbus¸ serial port¸ and wired and wireless communication (including optional GPS functionality)
Interface3：2 x MultiTech Compatible Sockets¸ 921Kbp/s maximum3.3V or 5V¸ up to 3.2A maximum
form factor：High voltage (2500V) port isolation reduces noise and increase system protection
Install：Jumperless configuration with secure lock¸ ensuring uniformity and maximizing system security
電源電圧： +5V DC¸ 600 mA maximum (+ socket power)
温度範囲： -40℃ to +85℃
ボードサイズ：PC/104 Compliant
その他仕様：Advanced CANbus functionality reduces development time¸ cost¸ and installation setup

仕様書ダウンロード

型番：PC/104
Interface1：8x Gigabit ethernet (10/100/1000 Mbps)
Interface2：Carrier Grade Ethernet Switching
Interface3：Available with RJ-45 or Rugged Locking connectors
form factor：8 or 12 Port 10/100/1000 Mbps Switch
Install：Available with RJ-45 or Rugged Locking connectors
電源電圧： +9V to +36V
温度範囲： -40℃ to +85℃
ボードサイズ：Fully PCI/104 compliant
適合GPU：Web GUI or CLI Management
冷却方式：Conduction cooled Heatplate or Air cooled Heatsink option

仕様書ダウンロード

型番：PC/104
Interface1：1x low pin count FPGA Mezzanine Card (LPC FMC)36 LVDS pairs¸ 1 rocket I/O channel¸ I2C interface
Interface2：Spartan-6 LX45T FPGA
Interface3：PCIe x1 form factor
form factor：128MB DDR3 Memory
Install：Low Pin Count FMC connector
電源電圧： +12V DC Input Only (DC Barrel)¸ +3.3V DC
温度範囲： -40℃ to +85℃
ボードサイズ：Height: 4.4” Length: 6.6”
その他仕様：2x 10/100/1000 Ethernet ports

仕様書ダウンロード

型番：PC/104
Interface1：Burn-in ten PCI Express cards with lane widths from x1 to x16 in any combination
Interface2：Front-located test points for easy measurement of both +3.3V and 12V rails
Interface3：ATX power – 20 and 24 pin options (on/off switch control)¸ Optional: Binding posts to allow the connection of a bench power supply
form factor：Quick verification of power conditions and lane widths via on board LEDs
Install：ATX power – 20 and 24 pin options (on/off switch control)¸ as well as binding posts to allow the connection of a bench power supply
電源電圧： +3.3V and 12V rails
温度範囲： -40℃ to +85℃
ボードサイズ：Length: 31.5cm/12.4” Width: 13.97cm/5.5”

仕様書ダウンロード

型番：PC/104
Interface1：x1 lane PCIe (PCI Express 1.1 compliant)
Interface2：Push button generation of Non-Maskable Interrupt (NMI)
Interface3：Transparent PCIe to PCI bridge
温度範囲： 0℃ to +65℃
ボードサイズ：Standard MD1 low profile format (2.57” long)
その他仕様：Compatible with all Windows¸ Linux and QNX operating systems

仕様書ダウンロード

型番：PC/104
Interface1：PCI-104 120 pin connector¸ PCIe/104 156 pin connector¸ x1 lane PCI Express card edge
Interface2：PCIe/104 156-pin connector
Interface3：PCI-104 120-pin connector
form factor：x1 lane PCI Express card edge allows installation in any slot width
Install：Complies with PCI Express 1.1 electromechanical requirements
温度範囲： -40℃ to +85℃
ボードサイズ：4.375″ x 4.050″

仕様書ダウンロード

型番：PC/104
Interface1：x1 Lane PCI Express card compatible with any available x1¸ x4¸ x8 or x16 PCI Express slot.
Interface2：Speed: Bidirectional data communication speeds up to 1.8432 Mbps (RS-422/485) and 921.8Kbps (RS-232)
Interface3：Each port has up to 64 bytes of transmit and receive FIFO buffers¸ automatic hardware and software flow control for your PCI Express applications
電源電圧： +3.3V DC @ 400mA (typical)
温度範囲： 0℃ to +70℃
ボードサイズ：2 and 4 port models: Length: 10.86 cm/4.275″ Height: 10.92 cm/4.300″¸ 8 and 16 port models: Length: 14.699 cm/5.775″ Height: 11.1125cm/4.375″
その他仕様：Protection: Surge suppression and optical isolation options

仕様書ダウンロード

型番：PC/104
Interface1：PCI Express x1 Lane lane serial card¸ 8 or 16 ports RS-232
Interface2：Speed: Bidirectional data communication speeds up to 921.8Kbps
Interface3：RS-232 line interface with 50 bps to 1 Mbps baud
form factor：Performance: RS-232 line interface with 50 bps to 1 Mbps baud
電源電圧： +3.3V DC @ 300mA (max)
温度範囲： -40℃ to +85℃
ボードサイズ：Length: 14 cm/5.5” (including bracket) Height: 10.7 cm/4.2”
その他仕様：Protection: Surge suppression options

仕様書ダウンロード

型番：PC/104
Interface1：PCI Express x1 Lane serial card
Interface2：4 or 8 ports individually isolated
Interface3：Any available x1¸ x4¸ x8 or x16 PCI Express slot
form factor：Switchable RS-232/422/485
Install：Supports full duplex (4 wire)¸ half duplex (2 wire) with auto TxD echo cancellation and multi-drop (4 wire) modes in RS-422/485
電源電圧：Port settings can be set up by software
温度範囲： -40℃ to +85℃
その他仕様：Bi-directional data speeds up to 7.8 Mbps (RS-422/485)

仕様書ダウンロード

型番：PC/104
Interface1：x1 Lane PCI Express card compatible with any available x1¸ x4¸ x8 or x16 PCI Express slot.
Interface2：Speed: Bi-directional data communication speeds up to 1.8432 Mbps (RS-422/485) and 921.8Kbps (RS-232)
Interface3：Each port has up to 64 bytes of transmit and receive FIFO buffers¸ automatic hardware and software flow control
form factor：Performance: Each port has up to 64 bytes of transmit and receive FIFO buffers¸ automatic hardware and software flow control
電源電圧： +3.3V DC @ 675mA (max)¸ 100mA (min)
温度範囲： -40℃ to +105℃
ボードサイズ：Length: 14.699 cm/5.787” Height: 6.891 cm/2.713″
その他仕様：Protection: IEC 61000-4 compatible on all signals¸ all ports

仕様書ダウンロード

型番：PC/104
Interface1：x1 Lane PCI Express card compatible with any available x1¸ x4¸ x8 or x16 PCI Express slot.
Interface2：Speed: Bi-directional data communication speeds up to 1.8432 Mbps (RS-422/485) and 921.8Kbps (RS-232)
Interface3：Each PCI Express port has up to 64 bytes of transmit and receive FIFO buffers¸ automatic hardware and software flow control
form factor：Performance: Each PCI Express port has up to 64 bytes of transmit and receive FIFO buffers¸ automatic hardware and software flow control
電源電圧： +12V DC @ 180mA¸ +3.3V DC @ 200mA
温度範囲： -40℃ to +105℃
ボードサイズ：Length: 15.7 cm/6.2” Height: 6.9 cm/2.7”
その他仕様：Protection: 3kV of optical isolation on each port

仕様書ダウンロード

型番：PC/104
Interface1：x1 Lane PCI Express card compatible with any available x1¸ x4¸ x8 or x16 PCI Express slo
Interface2：Speed: Bi-directional data communication speeds up to 1.8432 Mbps (RS-422/485) and 921.8Kbps (RS-232)
Interface3：Each port has up to 64 bytes of transmit and receive FIFO buffers¸ automatic hardware and software flow control
form factor：Performance: Each port has up to 64 bytes of transmit and receive FIFO buffers¸ automatic hardware and software flow control
電源電圧： +12V DC @ 180mA¸ +3.3V DC @ 200mA
温度範囲： -40℃ to +105℃
ボードサイズ：Length: 14.699 cm/5.775″ Height: 11.049 cm/4.350″
その他仕様：Protection: 3kV of optical isolation on each port

仕様書ダウンロード

型番：PC/104
Interface1：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
Interface2：PCIe/104 and PCI/104-Express compatible
form factor：PCIe/104 156-pin top connector
温度範囲： -40℃ to +85℃
ボードサイズ：193mm x 152mm
その他仕様：Custom support bracket to ensure PCIe card stability

仕様書ダウンロード

型番：PC/104
Interface1：Footprint for 2x USB Type B connectors¸ PCI-104/Express 156 pin top connector¸ x16 vertical PCI Express card edge connector (supports x1¸ x4¸ x8¸ x16)
Interface2：x16 lane vertical PCI Express card edge connector (fits any x1¸ x4¸ x8 or x16 lane cards)
Interface3：PCIe/104 and PCI/104-Express compatible
form factor：PCIe/104 156 pin bottom connector
温度範囲： -40℃ to +85℃
ボードサイズ：95.885mm x 90.17mm
その他仕様：Custom support bracket to ensure PCIe card stability

仕様書ダウンロード

型番：PC/104
Interface1：x1 PCIe/104 lanes can be connected via PCI Express cable
Interface2：Compatible with PCIe/104 and PCI/104-Express
Interface3：PCI Express Cabling Specification 1.0 Compliant
form factor：Optional configurable PCIe signal repeater to support longer cable lengths
温度範囲： -20℃ to +85℃
ボードサイズ：95.885mm x 90.17mm

仕様書ダウンロード

型番：Universal PCI
Interface1：RS-232: TxD¸ RxD¸ RTS¸ CTS¸ SG¸ RI¸ DTR¸ DSR¸ DCD¸ RS-422/485: TxD +/- ¸ RxD +/- ¸ RTS +/- ¸ CTS +/-¸ SR
Interface2：Two¸ four or eight asynchronous serial ports in various electrical interface configurations.
Interface3：Octal PCI UART with up to 64 byte transmit and receive FIFO buffer
form factor：Supports full duplex (4 wire) with RTS/CTS flow control¸ half duplex (2 wire) with auto TxD echo cancellation and multi-drop (4 wire) duplex communication modes in RS-244/485.
Install：Each port can be configured independently for baud rate¸ parity¸ data and stop bits.
電源電圧：100 mA min¸ 5V @ 875 mA max.
温度範囲： -55℃ to +105℃
ボードサイズ：Length: 14.702 cm/5.788” Height: 10.605 cm/4.175
その他仕様：Maximum data speeds of 921.6 Kbps (RS-232) and 1.843 Mbps (RS-422/485).

仕様書ダウンロード

型番：Universal PCI
Interface1：Universal PCI ensures this Low Profile serial card fits into both 3.3V or 5V systems. Available with standard height PCI bracket and cabling options as well.
Interface2：Speed: Supports data communication speeds up to 1.8432 Mbps.
Interface3：Each port is controlled by a dual¸ quad or octal PCI UART¸ providing 64 bytes of transmit and receive FIFO buffers¸ global interrupt source register¸ automatic hardware and sof
form factor：Protection: Available multi-strike surge suppression on all signals¸ all ports.
電源電圧：100 mA min¸ 5V @ 875 mA max.
温度範囲： -55℃ to +105℃
ボードサイズ：Length: 14.702 cm/5.788” Height: 10.605 cm/4.175
その他仕様：Protection: Available multi-strike surge suppression on all signals¸ all ports.

仕様書ダウンロード

型番：Universal PCI
Interface1：Universal PCI ensures this Standard Profile serial card fits into both 3.3V or 5V systems.
Interface2：Speed: Supports data communication speeds up to 1.8432 Mbps.
Interface3： Ports are controlled by an octal PCI UART¸ providing 64 bytes of transmit and receive FIFO buffers¸ global interrupt source register¸ automatic hardware and software flow control.
form factor：Performance: Ports are controlled by an octal PCI UART¸ providing 64 bytes of transmit and receive FIFO buffers¸ global interrupt source register¸ automatic hardware and software flo
電源電圧：5V @ 875 mA max.¸ 100 mA min.
温度範囲： -55℃ to +105℃
ボードサイズ：Length: 14.702 cm/5.788” Height: 10.605 cm/4.175
その他仕様：Protection: Available multi-strike surge suppression on all signals¸ all ports.

仕様書ダウンロード

型番：Universal PCI
Interface1：Suitable for both 3.3V and 5V PCI slots.
Interface2：Speed: Supports data communication speeds up to 1.8432 Mbps.
Interface3：Dual UARTs¸ providing 64 bytes of transmit and receive FIFO buffers for each port.
form factor：Flexibility: Suitable for both 3.3V and 5V PCI slots.
電源電圧：100 mA min¸ 5V @ 875 mA max.
温度範囲： -55℃ to +105℃
ボードサイズ：Length: 14.702 cm/5.788” Height: 10.605 cm/4.175
その他仕様：Protection: 3kV optical isolation on all ports.

仕様書ダウンロード

型番：Universal PCI
Interface1：Universal PCI ensures this Standard Profile serial card fits into both 3.3V or 5V systems.
Interface2：Speed: Supports data communication speeds up to 921.6 Kbps.
Interface3：Eight UART channels providing 64 bytes of transmit and receive FIFO buffers¸ global interrupt source register¸ automatic hardware and software flow control.
form factor：Protection: Surge suppression on all signals¸ all ports.
電源電圧： +12V¸ +5V
温度範囲： -55℃ to +105℃
ボードサイズ：Length: 12.129 cm/4.775″ | Height: 10.668 cm/4.2″

仕様書ダウンロード

型番：PCI/104
Interface1：Eight ports of 20mA Current Loop interface.
Interface2：Speed: Supports baud rates up to 57.6 Kbps.
Interface3：State of the art UARTs control each port providing 64 bytes of transmit and receive FIFO buffers.
form factor：Reliability: Optically isolated Current Loop interface when connected in passive mode.
電源電圧： +5V DC @ 375mA (typ)+/- 12V DC @ 320mA (max)(Can be operated with +12V DC only to conserve power)
温度範囲： -65℃ to +150℃
ボードサイズ：Height: 10.50 cm / 4.13″Length: 18.00 cm / 7.09″Width: 1.50 cm / 0.59″Weight: 0.12 kg / 0.26 lbs
その他仕様：Easy installation: Plug and Play means you’re up and running with little effort.

仕様書ダウンロード

型番：PCI/104
Interface1：Available in 2 and 4 port densities with switchable RS-485 and RS-232 line interfaces.
Interface2：Optical Isolation: Each port is individually optically isolated at 3.0 kV AC* peak to peak.
Interface3：Supports all three RS-485 modes Full Duplex with RTS/CTS flow control. Half Duplex with Auto TxD echo cancellation. Multi-drop Slave with 4 wire full duplex communication of multi-drop devices.
form factor：Speed: Supports data transfer rates up to 921.6 kbps under RS-485.
Install：Performance: State of the art UARTs control each port providing 128 bytes of transmit and receive FIFO buffers.
電源電圧：2 port model: +5V DC @ 320mA (typ)4 port model: +5V DC @ 500mA (typ)
温度範囲： -40℃ to +150℃
ボードサイズ：Width: 10.60 cm / 4.17″Length: 19.50 cm / 7.68″Height: 1.12 cm / 0.44″
その他仕様：Adaptability: Supports all three RS-485 modes Full Duplex with RTS/CTS flow control. Half Duplex with Auto TxD echo cancellation. Multi-drop Slave with 4 wire full duplex communication of multi-drop d

仕様書ダウンロード

型番：PCI/104
Interface1：High performance UARTs control each port providing 64 bytes of transmit and receive FIFO buffers and automatic flow control.
Interface2：Speed: Supports baud rates up to 1382.4 Kbps.
Interface3：On-board RJ-11 connectors for six ports¸ and male DB-9 connectors/cables for two ports.
電源電圧： +/- 12V DC @ 144mA (typical)¸ +5V DC @ 400mA (typical)
温度範囲： -65℃ to +150℃
ボードサイズ：Height: 10.50 cm / 4.13″Length: 12.25 cm / 4.82″Width: 1.50 cm / 0.59″Weight: 0.12 kg / 0.26 lbs
その他仕様：Easy installation: No DIP switches or jumpers to set¸ simply Plug and Play!

仕様書ダウンロード

型番：PCI/104
Interface1：Flexibility: 2¸ 4 or 8 asynchronous RS-232 serial ports.
Interface2：Speed: Supports data communication speeds up to 1382.4 Kbps.
Interface3：Performance: Each port is controlled by 16C654 UARTs¸ providing 64 bytes of transmit and receive FIFO buffers.
form factor：Protection: Multi-strike surge protection on all signals¸ all ports.
電源電圧： 2 port model: +5V DC @ 240mA (typ); +/- 12V DC @ 32mA (typ)4 port model: +5V DC @ 280mA (typ); +/- 12V DC @ 57mA (typ)8 port model: +5V DC @ 400mA (typ); +/- 12V DC @ 144mA (typ)
温度範囲： -65℃ to +150℃
ボードサイズ：Height: 9.68 cm / 3.81″Length: 12.66 cm / 4.98″Width: 1.50 cm / 0.59″
その他仕様：Easy to install: Plug and Play means no DIP switches or jumpers to set. A comprehensive manual and software driver will get you up and running in no time.

仕様書ダウンロード

型番：PCI/104
Interface1：2¸ 4 and 8 port densities with RS-485 and RS-232 line interfaces.
Interface2：Speed: Supports data communications speeds up to 921.6 Kbps.
Interface3：Support for all three RS-485 modes Full Duplex with RTS/CTS flow control. Half Duplex with Auto TxD echo cancellation. Multi-drop offers four wire full duplex communication of multi-drop devices.
form factor：Performance: High performance UARTs control each port providing 128 bytes of transmit and receive FIFO buffers¸ automatic flow and RS-485 control.
Install：Protection: Multi-strike surge protection on all signals¸ all ports.
電源電圧： +5V
温度範囲： -65℃ to +150℃
ボードサイズ：8 port models:Height: 10.50 cm / 4.13″Length: 17.30 cm / 6.81″Width: 1.50 cm / 0.59″2 & 4 port models:Height: 10.50 cm / 4.13″Length: 12.00 cm / 4.72″Width: 1.50 cm / 0.59″
その他仕様：Easy installation: Plug and Play means no DIP switches or jumpers to set. A comprehensive manual and software driver will get you up and running in no time.

仕様書ダウンロード

型番：PCI/104
Interface1：One NT960/PCI Host Adapter can handle up to 128 ports.
Interface2：Performance: Basis Communications CD1400 communication controllers¸ with 12 byte Rx and 12 byte Tx FIFO buffers on every port¸ offer data communications up to 115.2 Kbps.
Interface3：The NT960/PCI host adapter combined with the ACM/Flex16 can support multiple electrical interfaces (RS-232¸ RS-422/485¸ 20mA Current Loop) through one computer slot.
Install：Easy installation: No jumpers or DIP switches to set. Fully Plug and Play.

仕様書ダウンロード
